Dutch Cone Penetrometer 5 Ton Capacity
ASTM D3441
For determining cone resistance and friction resistance of soil layers.
Consist of :
- Press-In Apparatus : Steel construction, manually operated 5 tons capacity.
- Sounding Rod : Machined steel, 36 mm o.d., 1 mtr effective length, tappered thread.
- Plunger Rod : Round bar, 15 mm dia, 1 mtr length.
- Push Adaptor : Machined steel.
- Pull Adaptor : Machined steel.
- Spiral Anchor : Machined steel, welded 1.5 m length.
- Handle And T-piece : Machined steel, welded.
- Mantel Cone : Precision machine steel hardened tip, tappered thread. 60º angle, 35.7 mm diameter.
- Friction Cone : Precision machine steel hardened, with friction jacket, tappered thread 60º angle, 35.7 mm diameter.
- Wrenches Set : Pipe wrench (2), adjustable wrench (1), spanner wrench, allen key (1), screw driver (1), oil can (1), steel brush (1), piston wrench (1), seals tape (2), oil seals (2), steel box (1). (1 Set)
- Fasten press : Beam Cannal.
- Long Fasten Press : 1.8 m length, 12 cm width.
- Short Fasten Press : 1.2 m length, 15 cm width.
- Manometer : 60 kg/ cm² cap, single pointer, 6″ dia, lower mount connection.
- Manometer : 500 kg/ cm² cap, single pointer, 6″ dia, lower mount connection.
Dimension (l x w x h): 220 x 120 x 80 cm / Gross weight: 500 kg
