For determining cone resistance and friction resistance of soil layers.
Consist of :
Hydraulic Driving Appliance : Steel construction, hydraulic operated 5 Ton Capacity single cylinder pressure, sounding speed 2 cm/ sec. incorporated two wheel integral with the driving appliance. Penetration measuring scale 100 cm assembly on body. The standard measuring device is equipped with two pressure gauges. The trailer is suitable for towing behind a truck.
Manometer : 60 kg / cm² capacity, lower mount connection.
Manometer : 500 kg / cm² capacity, lower mount connection.
Power Unit : Hydraulic pump incorporated in governor matched to the installed petrol engine, 9.5 HP, hand starter.
Sounding Rod : Machined steel, 36 mm o.d., 1 mtr effective length, tappered thread.
Plunger Rod : Round bar, 15 mm dia, 1 mtr length.
Push Adaptor : Machined steel.
Pull Adaptor : Machined steel.
Anchoring Pickets : Machined steel, welded, spiral type anchor with screw pickets, 1.2 metre length.
Hydraulic Spanner : Machined steel, hydraulic gear box powered with variabel speed gasket, additional hand spanner for spare.
