For determining cone resistance and friction resistance of soil layers.
Consist of :
Hydraulic Driving Appliance : Steel construction, hydraulic operated 10 Ton Capacity Design with double cylinder pressure, sounding speed 2 cm/ sec. incorporated two wheel integral with the driving appliance. Penetration measuring scale, 100 cm assembly on body. The standard measuring device is equipped with two pressure gauges.
Manometer : 100 kg / cm² capacity, lower mount connection.
Manometer : 1000 kg / cm² capacity, lower mount connection.
Power Unit : Hydraulic pump incorporated in governor matched to the installed petrol engine, 13.5 HP, hand starter.
Sounding Rod : Machined steel, 36 mm o.d., 1 mtr effective length, tappered thread.
Plunger Rod : Round bar, 15 mm dia, 1 mtr length.
Push Adaptor : Machined steel.
Pull Adaptor : Machined steel.
Anchoring Pickets : Machined steel, welded, spiral type anchor with screw pickets, 1.4 metre length.
Hydraulic Spanner : Machined steel, hydraulic gear box powered with variabel speed gasket, additional hand spanner for spare.
