Direct Shear Test Hand Operated

Direct Shear Test Hand Operated

ASTM D-3080  /  AASHTO T-236

For determining shearing resistance of soil sample.

Loading Machine Consist of :

  • Frame : Welded steel frame, hand operated gear box, 100 kg cap.
  • Loading Hanger : Machine steel, galvanized, supplied without load.
  • Shear Box : Cast alumunium box, 63.5 mm sample diameter,porous stone, loading capacity.
  • Loads : Slotted, machine steel, galvanized.
  • Load : 3167 gr weight.
  • Load : 6334 gr weight.
  • Sample Tube : Machine steel, 63.5 mm diameter, galvanized, with extruder.
  • Proving Ring : 100 kg capacity.
  • Dial Indicator : Range 10mm x 0.01mm.
  • Dial Indicator : Range 20mm x 0.01mm.
  • Wire Saw : 10 cm length approx.

Dimension (l x w x h) : 130 x 20 x 130 cm / Gross Weight : 125 Kg

Category: Alat Laboratorium Tanah

Related products

  • Compaction Permeameter Test

    For determining coeffisient of permeability of compacted soil sample

    Consist of :

    • Compaction Permeameter : 1/30 cu. ft. mold , 4 inch i.d,inlet-outlet connector, overflow valve, porous stone.
    • Frame : Cast alumunium base, alumunium column, 3 burette (5, 10, 15 mm diameter).
    • Graduated Cylinder : Glass made,100 ml capacity,single numbering.
    • Stop Watch : Precision timer, stainless steel body, 60 sec sweep x 30 min

    Dimension (l x w x h) : 30 x 30 x 50 cm/ Gross weight : 30 Kg



  • Speedy Moisture Tester

    AASHTO T-217;  SNI 03-1965.1-2000

    For determining the moisture content of soil by means of calcium carbide gas pressure meter.

    Consist of :

    • Speedy Gauge : M/C range 0-20 %, sens. : 0.2 %, sample  weight 20 gr.
    • Speedy Balance : Digital 200 gr capacity x 0.1 gr sensitivity.
    • Calcium Carbide :Reagent absorbent, CaC₂ calcium carbide
    • Measuring Spoon : Cast alumunium.
    • Crushing Ball : Steel ball, 31,7 mm diameter
    • Cleaning Brush : Plastic brush/ plastic holder
    • Carrying Case : Wooden case with handle

    Dimension (l x w x h): 45 x 45 x 30 cm / Gross Weight: 15 Kg



  • Consolidation Test

    ASTM D-2435  /  AASHTO T-216

    For determining the rate and magnitude of consolidation of soil when it is restrained laterally,loaded and drained axially.

    Consist of :

    • Frame : Cast alumunium, two test unit.
    • Loading set : Three alternative lever arm 1:9, 1:10, 1:11.
    • Consolidometer : Brass, 50.5 mm sample dia.,porous stone,loading capacity.
    • Loads : 500 gr weight.
    • Loads : 1000 gr weight.
    • Loads : 2000 gr weight.
    • Loads : 4000 gr weight.
    • Loads :8000 gr weight.
    • Sample Tube : Machine steel, 50.5 mm dia.galvanized, with extruder.
    • Dial Indicator : Range 10 mm x 0.01 mm.
    • Wire Saw : 10 cm length approx.

    Dimension (l x w x h) : 80 x 80 x 150 cm / Gross weight : 130 Kg
