Flash and Fire Point by Cleveland Open Cup
ASTM D-92 / AASHTO T-48
For determining flash and fire point by cleveland open cup for petroleum product and other liquids, except fuel oils and materials having an open flash point below 79°C (173°F) as determined by the cleveland open cup tester.
Consist of :
- Flash Cup: Brass, insulation handle.
- Burning Pipe : Brass pipe, insulation handle.
- Flash Cup Plate : Steel Plate.
- Support : Adjustable height metal, thermometer holder.
- Y-Connector : Brass, provided with gas hose.
- Bunsen Burner : Heat resources.
- Thermometer : Astm 11 C, 6 to 400°C.
Dimension (l x w x h) : 150 x 30 x 30 Cm / Weight (approx) : 8 Kg
BENKELMAN BEAM / BI-450
For measuring the deflection of flexible pavement under the action of moving wheel loads.
Fixed Beam (BI-451) Alumunium profile frame, 3 points adjuster, with vibrator and dial holder. Alumunium strip arm, 1:2 level ratio (1 set)
Tire Gauge (BI-455) 120 psi capacity (1 pc)
Surface Thermometer (BI-456) Range 0 – 100 deg.C (1 pc)
Dial Indicator (GE-137) Range 30 x 0.01 mm (1 pc)
Dimension (l x w x h) : 244 x 50 x 50 Cm/ Gross weight : 45 Kg
Standard supply with instruction manual books
Automatic Asphalt Compactor
Standard Testing : ASTM D-5581, BS 598-107, EN 12697-30
Features & Specification
The use automatic compaction will result in consistensi and repeatable laboratory specimens, suitable for ASTM or BS Standard. Testing houses and design consultants who use the marshall methode of mix design will benefit from automatic compaction apparatus, which releses staff for other work during the compaction process.
The unit incorporates :
Automatic Compactor Machine : Heavy-duty welded steel construction The equipment is suitable for operation on 300 Watt, 220 V-AC, 50 Hz, 1 Phase. Automatic counter, module system for easy maintenance ON-OF-RUN-STOP-RESET- 500 Blow.
Compaction Mould : 4 inch diameter, 3 inch height, with collar and base plate machine steel, galvanized.
Compaction Mould 6″ : 6 inch diameter, 3 1/2 inch height, with collar and base plate machine steel, galvanized.
Compaction Hammer 10 lbs : The standard hammer has a 4,536 kg (10 lbs) sliding weight with a free fall 457 mm.
Compaction Hammer 22.5 lbs : The hammer has a 10.206 kg (22.5 lbs) sliding weight with a free fall 457 mm.
Compaction Pedestal : Comprising 300 mm square x 25mm thick steel plate secured to an 200 mm square x 45 inch high wooden block, the specimen mould,clamp and hammer guide are fitted to the plated, provided withcompaction hammer guide stand 650mm height.
Overal Dimension (l xwxh) : 400 x 450 x 1800 mm approx. / Weight (approx) : 200 Kg
Centrifuge Extractor Test Set (Electric)
Standard Testing : ASTM D-2172 / AASHTO T-164; According SNI 03-6894-2002
For determining bitument content in hot mixed paving and pavement samples.
Consist of :
- Centrifuge Extractor : Electric, 220 V-AC, variable speed DC motor up to 3600 rpm, alumunium housing, removeable cover and bowl,1500 gram capacity.
- Filter Paper : Low ash filter paper, box of 50 sheet.
- Solvent : Perchloraethylen (PCE), bottled.
Dimension (l x w x h): 60 x 40 x 60 cm / Gross weight: 50 Kg
